We have tested the SRAM Force Rear Derailleur on, particularly steep climbs. As the tests were carried out over a duration of a few months, varying weather conditions were prevailing throughout.
Our Verdict: We needed some time to adjust to the Double Tap technology of the shifters here. This was followed up by riding a few miles as we flicked through gears here. This was necessary before we finally tried it out on the steep and long climbs. The shift response was impeccable as we tweaked a few cables. We used an SL-K FSA chainset here, which eliminated all friction. Overall, the SRAM Force Rear Derailleur was able to hold up all in a variety of riding conditions. We would urge you to use the SRAM Force groupset here, as the performance is guaranteed to be top-notch with this configuration.
|10-speed Exact Actuation compatible||Misalignment will create issues with shifting and handling the bike|
|Powerful 2-spring system|
|Utilizes Double Tap technology from SRAM|
|Built with cutting edge materials that do not compromise strength while making them durable|
SRAM Force Rear Derailleur: Offers great shift response, ideal for different types of riding conditions, serves good performance
- Speeds: 10s
- Shifter Compatibility: SRAM
- Cogsets: SRAM 10 s & 10s cogsets from Shimano
- Chains: 10 s SRAM Power chains & 10s chain from Shimano
- Cranks / Chainrings: Compatible with 10 s, 53-39/52-38/52-36/ 50-34 / 50-36
- Cable & Housing: High quality 1.1 mm shifting cable and 4-5mm compressionless, with mon sealed end caps of maximum 5.8 mm diameter and maximum length 16 mm
- Total: 33T
- Max Sprocket: 28T
- Min Sprocket: 11T
- Front Difference: 16T
- Parallelogram Spring: Steel
- Pulleys: Cartridge bearing
- Direct Mount: Yes
- B-Knuckle: Forged Aluminum
- Outer Link: Forged Aluminum
- Inner Link: Magnesium
- Outer Cage: Carbon
- Inner Cage: Aluminum
- Hanger Bolt: Aluminum
SRAM gears have found their way onto a variety of bikes used for adventure, gravel, and cyclocross. This is because most SRAM gears come in a 1x version. The gear range at the rear will be wider while a singular chainring is used at the front. These setups are becoming a standard on mountain bikes, and are easier to maintain. The SRAM levers tend to operate in a different mechanism for shifting, which is the double-tap system.
Features that allow its gear change to be precise
1. High-quality materials
Materials with cutting-edge properties have been used in the construction of the SRAM force rear derailleur. The outer cage has been crafted with carbon fiber, while magnesium is being used for the inner link. This combination allows the rear derailleur here to maintain a low weight despite exhibiting great strength. The B knuckle is using Aluminum too, while titanium is being used for the overall hardware. This is followed up by the finish, which runs warm gray( similar to other Force gruppo components). The design has sufficient capacity for chain wrap so that any combination of SRAM cassette or crankset can be used with it.
2. Exact actuation technology
SRAM Force rear derailleur can deliver accurate and clean shifting throughout the gear range for shifting that is available on the 10s cassettes it is ideally compatible with. This is possible thanks to Exact Actuation technology. SRAM was successful in applying the 1: 1 ratio for actuation that existed on their MTB components, where this is the ratio between the movement of the derailleur and travel of the shifter cable. Exact Actuation attempts to balance the hanger design of the rear derailleur, the tension in the cable, and the spacing between the tight cogs. This allowed SRAM to set up a fixed but very simple system for index shifting. If the derailleur can index smoothly, the chain will ring several times while it is on the cassette and is being shifted up & down while the crank is turned.
3. 10s compatibility
The SRAM Force rear derailleur is compatible with both standard and compact 10s SRAM & Shimano cranksets for road biking. The components for 10s SRAM are adaptable on both mountain and road bikes. For example, a rear derailleur for an MTB can be used with shifters for a road bike. While SRAM 10s & 11s bike components for an MTB are not mutually compatible, this is not the case for road bikes running similar cassettes. To accommodate cassettes of a wider range, the rear derailleurs have been redesigned.
4. Shifter compatibility
The rear derailleur can be used as new Shifters from SRAM that are using Double Tap Technology. This single shift lever allowed gear to change in every direction. As the shift lever is pushed inwards slightly in the direction of the front wheel, this results in an upshift by a single gear – to the next cog which is harder or smaller. Pushing the lever across the point of upshift makes it possible to downshift to three cogs that are easier or larger. The design is ergonomic for smaller hands so that it is possible to wrap the finger better on the lever
5. Hanger length
The hanger length is denoted by L in the diagram below. To ensure that the rear derailleur is delivering optimal performance, this length should be between 26 and 28mm.
6. Chain Gap
The distance between the pulley for the upper guide and the cog on which the chain is riding is referred to as the Chain gap. On the SRAM Force rear derailleur, the chain gap is large enough so that to and from the largest cog smooth shifting is possible. The gap is small enough as well so that irrespective of the cog, efficient and fast shifting is possible. The chain gap can be adjusted so that on both the smallest and largest cog, the chain gap is running a minimum of 6mm approximately.
How to troubleshoot your SRAM Force rear derailleur?
In the table below, we have brought up a few scenarios that you will face with the SRAM Force Rear Derailleur. This is filled with a brief statement about what might be the root of the problem, and how you can solve it.
|The chain may be jumping to the offset of the frame from the sprocket which was the smalleast||The screw of the high limit gear may not have been adjusted properly||Ensure that sprocket which is the smallest has been aligned with the guide pulley, by turning the H screw inwards|
|The chain cannot be shifted to the smallest sprocket||The screw of the high limit gear may not have been adjusted properly||Ensure that sprocket which is the smallest has been aligned with the guide pulley, by unscrewing the H screw|
|The plate of the inner cage is scraping the spokes||The screw of the low limit gear may not have been adjusted properly||Ensure that sprocket which is the largest has been aligned with the guide pulley, by turning the L screw inwards|
|Shifting is delayed||Between the sprocket and the guide pulley, the clearance is very large||The b screw has to be adjusted by counterclockwise rotation|
|Shifting feels rough||Between the sprocket and the guide pulley, the clearance is very small||The b screw has to be adjusted by clockwise rotation|
|When shifting to the smallest sprocket, it is becoming tough to maintain consistency||The cable has not been tensioned enough||The barrel adjuster on the shifter has to be turned anticlockwise|
|While shifting to the largest sprocket, it is taking more time||The cable has not been tensioned enough||The barrel adjuster on the shifter has to be turned clockwise|
|While shifting to the smallest sprocket, it is taking more time||The shifting cable may be too tight / The cable may have been poorly routed or experiencing too much friction||Check the cable housing for excessive bending, and whether it needs to be replaced or lubricated|
How do you tune the SRAM Force Rear Derailleur?
Tools needed: Hex key, 5 mm; Screwdriver Phillips #2; and 1 set pliers, needle nose
The H screw will need to be tightened first. Typically, the outer limit is adjusted by the h screw. Tighten this screw just until it feels the tightest.
The limit screw has to be backed until the cog of the derailleur cog is directly under the cog which is the cassette’s smallest. The limit screw will need to be turned by half of the full turn. Follow this up with slow pedaling and try to listen if the chain is making any excessive noise. The screw will need to be tightened until it is in contact with the 2nd cog and makes a rubbing noise. This is given the fact the chain makes no noise at all. Address the rubbing sound by backing the limit screw off by a quarter of a full turn. This sets the H screw. Finish this step by turning the Harel adjuster in an anticlockwise direction a few times.
You have to follow this up with indexing, where the guide pulls will need to be lined up beneath every respective cog. The rear derailleur will therefore be in an optimum position during every shift of the gears, delivering excellent performance. The barrel can be placed in several positions to achieve this.
During this process, ideally, you should have the outer front’s ring carrying the chain. As you are shifting to the 2nd cog from the smallest cog on the rear, the chain will not jump. You will be turning the barrel adjuster in an anticlockwise direction so that 1 complete turn is finished. The change needs to be attempted again, and the process will be repeated until we have the chain making a smooth jump. Remove any slack of the cable by pulling some of it through the bolt of the anchor cable and tightening the bolt again.
If you see that the chain is jumping by 2 cogs and you are shifting, you will need to be shifting back down as the barrel adjuster is turned by full 360 degrees, but in an anticlockwise direction. You will need to be shifting up by a single gear so that now, the chain is on the 2nd cog. Keep turning the barrel adjuster here until the chain is rubbing on the next cog. Continue to pedal and turn the barrel adjuster slowly, this time in a clockwise direction. Keep this up until the noise vanishes. This needs to be repeated for each of the cassette’s cogs. Follow any excess noise by turning the barrel adjuster 90 degrees clockwise. You will also need to go up and down repeatedly until the process is complete. After setting this, you will be setting the L screw.
The L stands for “Low” here, and is used to make adjustments to the inner limit. As this screw is being turned until the point where it feels the tightest, the chain will no longer fall from the biggest cog to the wheel. You will now be shifting to the ring that is positioned at the inner front and the rear cog which is the second largest. If you cannot shift to the rear cog which is the largest, it indicates that the L screw has been tightened too much. This is also indicated by excessive noise or when the chain is slowly going up. No such issues will mean that the L screw is tightened by the correct amount. To set the screw at this point, turn the screw by 90 degrees until easy shifting to the largest cog is possible. A crisp shift will indicate that the screw is set.
The B screw makes adjustments to the angle. To set the B screw now, you will need to be on the rear cog that is the largest and on the ring lying at the inner front. Check the gap here to see if it is between 5 and 6 mm. If the gear changes are smooth, along with crisp shifting then it is likely that the gap is correct. The B screw will need to be tightened to bring the guide pulley inwards. Loosen this screw to increase the gap. If the gap looks ok( you can also use a measuring tool), then the setup for your SRAM Force rear derailleur has been tuned perfectly.
The manufacturer SRAM has built up quite a reputation in the market of road bikes today, and the SRAM Force rear derailleur is a testament to the prowess of manufacturing along with engineering of the company. At 178g, this lightweight dirt component can deliver peak performance even after a significant number of miles on them.
